HYDROGEN PRE-COOLING HEAT EXCHANGERS H2PC™

High pressure hydrogen applications.

VPE applies the same technology used to fabricate its diffusion bonded microchannel heat exchangers (MCHEs) on these hydrogen pre-cooling heat exchangers (H2PCs™).  As a result, these heat exchangers are ideally suited for high-pressure hydrogen applications.

Inside a Diffusion Bonded Microchannel Heat Exchanger

A general overview of fabricating a diffusion bonded microchannel heat exchanger, also known as a printed circuit heat exchanger:

  1. At first, the thermal engineering team calculates the design needed to meet the requirements of the heat exchanger.
  2. Secondly, an outside manufacturer etches plates or shims with the flow design.
  3. Thirdly, VPE assembles the shims in a counter-flow configuration.
  4. Fourthly, the stacked plates are diffusion bonded to create a solid heat exchanger core without gaskets.  Perfected since 1976, VPE’s proven diffusion bonding process ensures parent material strength throughout the core of the heat exchanger.
  5. Following, the diffusion bonded core is machined to size at VPE’s machine shop.
  6. Afterward, the welding team joins the required manifolds, flanges, and components to the core of the heat exchanger.
  7. Later, VPE carefully cleans and tests the heat exchanger to verify it is leak proof.
  8. Last, VPE’s diffusion bonded microchannel heat exchangers are “U” or “UM” stamped and meet the requirements of the ASME Boiler and Pressure Vessel Code.
hydrogen pre-cooling heat exchangers H2PC™
VPE Heat Exchanger Certifications

Advantages of Hydrogen Pre-Cooling Heat Exchangers

There are many advantages of hydrogen pre-cooling heat exchangers (H2PCs™) e.g.:

  • Firstly, the heat exchanger core is diffusion bonded to create a solid core without gaskets, interlayers, or brazing.
  • Secondly, the counter-flow configuration of the microchannels causes close-approach temperatures.
  • Next, the core design handles the maximum design pressures of the two streams at the highest temperature, which enhances safety.
  • Also, H2PCs™ are incredibly resistant to vibrations and catastrophic failure modes.
  • In addition, there is a highly compact construction (high heat transfer area/volume ratio) for the productive use of small spaces relative to other configurations.
  • Furthermore, there are significant savings with low weight and fluid inventory.  As a result, the H2PCs™ have a small footprint and can fit inside a dispenser cabinet.
  • There is a small cooling energy overhead (small thermal mass).
  • Also, the B2B fill capability is virtually infinite.
  • Last, the purchase cost meets the DOE budget, and the shipping and installation cost is low.

Hydrogen Pre-Cooling Heat Exchangers Continue to Surpass Rigorous Testing

VPE manufactures hydrogen pre-cooling heat exchangers (H2PCs™) for high pressures and high temperatures.  Additionally, we design  H2PCs™ up to 1275 barg pressure capability.   As a result, H2PCs™ withstand high pressures in hydrogen pre-cooling applications.

At the present time, Sandia National Laboratories studies the H2PCs™ which continue to easily surpass the rigorous standards.

  • Sandia National Laboratories is performing the testing.
  • H2PCs™ are surpassing the continuous and rigorous 70,000 hydrogen gas pressure cycles.
  • The testing continues 24/7.
  • There have been exceptional test criteria showing hermeticity to He (<10^-09 ml/sec) after cycling.
  • The test pressure cycle is 0 barg to 900 barg with a ramp-up rate of 240 barg/min and with less than a second pressure ramp-down rate.
hydrogen pre-cooling heat exchangers H2PC™

Above is a picture of a cutout of the inner core of a diffusion bonded microchannel heat exchanger (MCHE). This picture shows the layers of plates with flow channels.  During diffusion bonding, the atoms diffuse together and the core becomes one solid piece at parent material strength.

For Use in Hydrogen Fueling Stations

VPE offers various sizes of hydrogen pre-cooling heat exchangers (H2PCs™) and hydrogen recuperators for use in hydrogen fueling stations.

  • There are various sizes of H2PCs™ for different hydrogen fill rates.
  • H2PCs™ can handle pressures at 1000+ barg
  • Hydrogen fueling stations use H2PCs™.
  • The hydrogen pre-cooling heat exchangers address the operational and cost targets established by the department of energy (DOE).
  • H2PCs™ meet the SAE J2601 specifications.
hydrogen pre-cooling heat exchangers H2PC™

Design and Operating Features for H2PC™ Models

MODELSH2PC™1H2PC™2H2PC™4H2PC™8H2PC™10H2PC™12
Hydrogen fill rates in kg/min
(SAE J2601 and beyond)
Covering forklift, light duty vehicles, heavy duty trucks, buses, trains, etc.)
< 1~ 2~ 4~ 8~ 10~ 12
Number of hydrogen side dispenser line options.
Various nozzle orientation - easily configurable
SingleSingle and dualMultiple
Typical operating inlet temperature range20°C to 65°C
Operating exit temperature range
(depending on customer application)
0°C to -40°C
(Hydrogen recuperators use cold side hydrogen inlet at -196°C)
Heat exchanger design temperature (Max / Min)100°C / -196°C
Operating pressure range350 barg to 950 barg
Heat Exchanger design pressure in barg500 (for 350 operating); 1000 - 1275 (for > 700 operating)
Typical coolant types usedSyltherm XLT, R744 (CO2), Freezium-60, d-limonene, dynalene HC, Temper 60, Therminol D12, glycol-water mix, liquid nitrogen and other refrigerants
Typical hydrogen side connection typesMedium pressure cone and threaded fittings; Pipe butt welded nozzle option is also available
Typical coolant side connection typeSwagelok (straight and elbows), ANSI Flanges (CI 150 RF, CI 300 RF)
Typical MTTFd and design life- MTTFd > 50 years, based on 24 hrs operation for 365 days in a 3 minute cycle operation.
- Can handle very high-pressure cycle fatigue
Typical material of constructionSS 316L (UNS 31603)
Certifications- ASME U & UM Stamps
- PED Compliant with CE marking

H2PC™ Models Compared to Alternative Heat Exchangers

 ALTERNATIVEVPE H2PC™
PHYSICAL SIZELarge mass and volumeSmall mass and volume (high heat transfer area / volume ratio)
COOLING ENERGY OVERHEADLarge cooling overhead (large thermal mass)Small cooling overhead (small thermal mass)
B2B FILL CAPABILITYHX size increases with number of B2B fillsVirtually infinite
PACKAGING / FOOTPRINTLarge footprintSmall foot print - Sizes range from hand-held size for mobile fueling to those that fit stationary fueling cabinets.
COSTPurchase cost low, shipping and installation cost highCapital cost well below alternative. Low shipping and installation cost provide additional savings.

Equipment & Facilities for Heat Exchangers

VPE owns over 150,000 square feet of design, lab, production, and quality assurance space.  hydrogen pre-cooling heat exchangers use the equipment and facilities below.

  • Diffusion bonding furnaces
  • The world’s largest vacuum hot press
  • Machine shop
  • Quality assurance facility
  • Welding cells
  • Cleaning lines
  • Assembly lines

Advantages of Working With VPE

VPE provides the metallurgical services, engineering, and contract manufacturing expertise our customers require to meet their demanding performance, cost, and lead-time goals.  Additionally, we work closely with OEMs, suppliers, and technology integrators to create the most efficient and effective diffusion bonded microchannel heat exchangers.

  • Over 45 years of diffusion bonding experience.
  • Design and manufacturing with engineering assistance.
  • Tested and proven manufacturing processes.
  • Redundant and burst capacity facility for fast turn and reliable sourcing.
  • State-of-the-art technical facilities.
  • Large-assembly diffusion bonding experience and facility.
  • Developed supply chain.
